Premium Quality Electric Trim Tab Systems

For boats 17’ to 60’ that require helm controlled trim tabs.

Lectrotab designs and manufactures premium quality electromechanical trim tab systems for the leisure and commercial marine markets. The Lectrotab system is easy to install on new boats or to replace existing trim tabs.

Lectrotab Stainless Steel Trim Tab

The Lectrotab stainless steel trim tab design provides unmatched strength and reliability. All stainless steel tabs are fabricated with a continuous rolled and pinned hinge. This design eliminates the need for welding. The tabs are made of corrosion resistant 12 gauge, 304 stainless steel.

Standard tabs are available in 9″ (23cm) and 12″ (30cm) chord lengths (chord is the length from the transom to the tab trailing edge) and in widths between 9″ (23cm) and 18″ (122cm).

Easy installation, typically within a few hours or less.

  • 12 gauge 304 Stainless Steel
  • Lifetime Actuator Warranty
  • Actuator Load Tested to 1000 Lbs.
  • Patented O-ring sealing system design
  • Patented Pressure equalization system to prevent water leaking
  • Whisper quiet Actuator Operation from planetary Gearbox and high efficiency motor
  • Double insulated Electric Actuator (per ABYC E-11-.17.2.3 specs) prevent stray current galvanic corrosion
  • 100% Quality control testing at each stage of assembly.
  • Precise Release Positioning (PRP) eliminates actuator drift when switch is released.
  • Sold as complete Kits including helm control switches.

Lectrotab Trim Tab Actuators

Precision-engineered to combine quiet operation with a non-hydraulic, maintenance free design. The unit is corrosion free, ensures very accurate tab positioning, provides maximum lift force, and is totally self-contained for easy installation. The actuator assembly is packaged in a non-metallic permanently sealed housing. No components need to be installed inside the boat. Unlike hydraulic trim tabs, there is no oil to leak out. The actuator incorporates either a standard or low profile transom mounting bracket. Actuators come in 12 VDC with 8 second recommended stroke time.

Lectrotab Control Switches

We offer a wide range of high quality, waterproof switches to suite your boating needs. From manual control to automatic control, Lectrotabs high tech switches are the most innovative trim tab switches on the market today. Lectrotabs now has 4 of its most innovative switch kits to date. Lectrotab switches provide instant response at the touch of a button allowing customers to position and balance their boat with ease.

Rocker Switch

part# FRS

Performs all standard trim tab control functions.

• Improved sealing to prevent water entry

• Higher load rating

• Recessed rocker prevents breaking

One-Touch Control

part# SLC-11

Combines a microprocessor based trim tab control with LED tab position indicators.

• One-Touch operation with LED tab position indicators

• Dedicated buttons for simultaneous movement of both tabs up and down

• Automatic tab position return

• Completely sealed and waterproof

Manual Leveling Control

part# MLC-1

Manually operated LED control with one touch tab positioning.

• Single button touch to raise/lower both tabs

• Tabs automatically return to previous position

• Completely sealed and waterproof

• No external power module required

Automatic Leveling Control

part# ALC-1

Automatically corrects roll and pitch for a more comfortable boating experience.

• Controls pitch and roll automatically

• Completely sealed and waterproof

• Automatic tab retraction

• No external power module required

For boats 17’ to 60’ that require helm controlled trim tabs the following Lectrotab systems are recommended.

Nauticus # DescriptionTypical ApplicationPrice
N9-9RS
XKAF9X9
9” X 9” Plates w/Rocker Switch Complete Set17’to 20’ boats$529.98

N9- 12RS
XKAF9X12
9”X 12” Plates w/Rocker Switch Complete Set21’ to 25’ boats $549.78

N12-12RS
XKAF12X12
12”X 12” Plates w/Rocker Switch Complete Set26’ to 34’ boats $598.99

N9-24RS
XKAF9X24
9”X 24” Plates w/Rocker Switch Complete Set 35’ to 40’ boats $825.59

N9-36RS
XKAF9X36
9”X 36” Plates w/Rocker Switch Complete Set 41’ to 60’ boats $1,591.98

Nauticus # DescriptionTypical ApplicationPrice
N9-9SLC
XKASL9x9
9” X 9” Plates w/ One Touch Control LED Switch Complete Set17’to 20’ boats$529.98

N9- 12SLC
XKASL9X12
9”X 12” Plates w/ One Touch Control LED Switch Complete Set21’ to 25’ boats $716.85

N12-12SLC
XKASL12X12
12”X 12” Plates w/ One Touch Control LED Switch Complete Set26’ to 34’ boats $753.38

N9-24SLC
XKASL9X24
9”X 24” Plates w/ One Touch Control LED Switch Complete Set35’ to 40’ boats $1,003.59

N9-36SLC
XKASL9X36
9”X 36” Plates w/ One Touch Control LED Switch Complete Set41’ to 60’ boats $1,770.29

Nauticus # DescriptionTypical ApplicationPrice
N9-9MLC
XKASML9X9
9” X 9” Plates w/Manual Switch Complete Set17’to 20’ boats$722.98

N9- 12MLC
XKASML9X12
9”X 12” Plates w/Manual Switch Complete Set21’ to 25’ boats $735.98

N12-12MLC
XKASML12X12
12”X 12” Plates w/Manual Switch Complete Set26’ to 34’ boats $871.98

N9-24MLC
XKASML9X24
9”X 24” Plates w/Manual Switch Complete Set35’ to 40’ boats $1,159.98

N9-36MLC
XKASML9X36
9”X 36” Plates w/Manual Switch Complete Set41’ to 60’ boats $1,776.33

Nauticus # DescriptionTypical ApplicationPrice
N9-9ALC
XKASAL9X9
9” X 9” Plates w/Auto Level Control Switch Complete Set17’to 20’ boats$1,227.15

N9- 12ALC
XKASAL9X12
9”X 12” Plates w/Auto Level Control Switch Complete Set21’ to 25’ boats $1,239.30

N12-12ALC
XKASAL12X12
12”X 12” Plates w/Auto Level Control Switch Complete Set26’ to 34’ boats $1,263.98

N9-24ALC
XKASAL9X24
9”X 24” Plates w/Auto Level Control Switch Complete Set35’ to 40’ boats $1,513.89

N9-36ALC
XKASAL9X36
9”X 36” Plates w/Auto Level Control Switch Complete Set41’ to 60’ boats $2,280.98

Note: RS = Rocker Switch (W/O Lights)    SLC = LED Position indicator Lights in Switch   MLC= Manual Leveling Control   ALC= Automatic Leveling Control

Customer Service: 8:00 am to 5:00 pm (EST) Monday to Friday (888-532-8768) Limited Technical service 24 Hrs., 7 days per week

Delivery: 3 to 5 Days from receipt of order

Shipping/ Handling: Shipping Added, No Handling Charges
